Teryair Air Motors: Reliable, Versatile, and Built for Extreme Conditions
Teryair Air Motors are stall-proof, self-cooling, high power-to-weight ratio, ATEX explosion-proof, and reversible-making them the preferred choice for a wide range of applications. These versatile workhorses excel in diverse environments where their unique features offer significant advantages over electric or hydraulic options. These compressed air motors are ideal for mixing, lifting, and pulling tasks in explosive zones. The speed and torque can be easily adjusted by modulating the input air pressure and air volume, providing flexibility to meet various operational needs. These air motors can be loaded to stall points without sustaining damage, allowing them to handle variable loads with ease. Additionally, they are designed to operate safely in hazardous environments where electrical motors might pose risks. A key benefit of Teryair air motors is their compact size compared to electric motors. We also offer lubrication-free versions, suitable for hygienic applications where cleanliness and corrosion resistance are essential. Apart from the standard rugged SG Iron versions, we also offer light weight versions with aluminum endplates and Stainless Steel versions for hygienic applications.
Max Power : 0.33 KW, 0.45HP
Speed at max power : 7600 rpm
SG Iron Motor: 1.0 kg (2.2 lbs)
Aluminum Motor: 0.8 kg (1.7 lbs)
Stainless Steel Motor: 1.0 kg (2.2 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 0.33 KW, 0.45HP
Speed at max power : 10000 rpm
SG Iron Motor: 1.0 kg (2.2 lbs)
Aluminum Motor: 0.8 kg (1.7 lbs)
Stainless Steel Motor: 1.0 kg (2.2 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 0.33 KW, 0.45HP
Speed at max power : 3000 rpm
SG Iron Motor: 3.1 kg (6.8 lbs)
Aluminum Motor: 2.3 kg (5.0 lbs)
Stainless Steel Motor: 2.8 kg (6.2 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 1.3 KW, 1.70HP
Speed at max power : 3000 rpm
SG Iron Motor: 4.0 kg (8.8 lbs)
Aluminum Motor: 3.1 kg (6.8 lbs)
Stainless Steel Motor: 6.1 kg (13.4 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 3.00 KW, 4.0HP
Speed at max power : 3000 rpm
SG Iron Motor: 7.6 kg (16.7 lbs)
Aluminum Motor: 5.4 kg (11.9 lbs)
Stainless Steel Motor: 7.6 kg (16.7 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 3.90 KW, 5.25HP
Speed at max power : 2500 rpm
SG Iron Motor: 11.4 kg (25.0 lbs)
Aluminum Motor: 10.0 kg (22.0 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
Max Power : 7.10 KW, 9.5HP
Speed at max power : 2000 rpm
SG Iron Motor: 36.1 kg (79.6 lbs)
Mounting: Hub / Foot / Face / Nema /IEC
Threading : NTP/ BSPP/ BSPT
FAQFrequently Asked Questions
Yes, we are spark-free and ideal for use in explosive and hazardous conditions.
Industries such as oil & gas, chemical processing, marine, and manufacturing commonly use.
The benefits are safer in hazardous environments, lightweight, and resistant to overheating.
Yes, solutions can be tailored based on specific industrial requirements.
You can consult Teryair experts to select the most suitable equipment based on your operational needs.
